PRODUCT Specs

General Information

Fuel type: Diesel
Mast type (standard): 4 stage / Telescopic boom
Capacity A: 8,000 lb (3,628.74 kg)
@ Lift height A: 35 ft (1,066.80 cm)
Capacity B: 1,200 lb (544.31 kg)
@ Forward reach B: 492 inch (12,496.80 mm)

Notes: 3,300lb capacity at max height 55'. Offset engine and low boom mount. Sway frame, quick attach system, auxilliary hydraulics, stabilizers.

Engine Specifications
Engine, make: JCB
Engine, model: 1004-40T
Rated power: 102 HP
Transmission, type: Powershift
Gears forward: 4
Gears reverse: 4

Dimensions and Weight
Max. lift height: 660 inch (16,764.00 mm)
Max. forward reach: 492 inch (12,496.80 mm)
Lowered height: 105 inch (2,667.00 mm)
Machine length: 250 inch (6,350.00 mm)
Machine width: 96 inch (2,438.40 mm)
Machine wheel base: 108 inch (2,743.20 mm)
Outside turning radius: 161 inch (4,089.40 mm)
Machine weight (no load): 26,808 lb (12,159.91 kg)
Gross weight (with load): 34,808 lb (15,788.64 kg)

Wheels, Tires and Brakes
Wheel number: 4
Wheels driven: 4
Brakes, type (service): Disc
